ST201D Ion Wind Snake Nozzle

Product Features:

1. A new type of static electricity eliminating device which uses compressed air to eliminate static

electricity and dust

2. Quick neutralization of static electricity and good electrostatic dust removal effect;

3. Ion airflow covers a large area and has a wide range of wind power regulation;

4. Small size, easy to install and adjustable in direction

5. Ion nozzle has good grounding protection function

6. Stickon ST401A high-voltage generator is required for integrated use

7. Outer sheath (blue bellows) can be added

Model Parameter	ST401A
Operating power supply	110V/60Hz or 220V/50Hz
Consumption current	0.23A or 0.12A
Power	75W
Operating temperature range	0-50℃
Weight	2.25kg
Length of high voltage wire	1.5m
Output voltage	4.6KV×2 or 4
Output current	4.5mA
Can it be used in explosion- proof environment	No

Technical Parameter

Model	ST201D
Ion generation mode	Ac type
Material of discharge needle	Wolfram steel
Host material	Iron/ABS fireproof engineering plastics
Air ion supply range	8cm~15cm
Air inlet pipe	Duct with inner diameter φ 8
Body size	The length of 550mm(L)×30mm(W)×86mm(H) standard cable is 2.5M
Appendix	Instructions/warranty cards/certificates
Performance	Static removal time < 1.5S
Air consumption	0.08m³/min
Noise	56DB
Ozone production	< 0.02ppm or less (measuring distance 200mm)

Product Siz
