ST202DF Sector Stainless Steel Bottom Box Ion Wind Snake Nozzle

Product Features:

1. Fan-shaped ion air nozzle is a kind of electrostatic eliminator with wide range and excellent performance,

especially designed for printing machine

2. It has the characteristics of simple installation, stable work, strong wind speed and fast static electricity

elimination, and can adjust the direction in a universal way, saving installation brackets

3. The air nozzle is made of ABS engineering fireproof plastic material with good temperature resistance, which

is not easy to burn out and break

4. It needs to be used with Stickon ST401A high voltage generator

5. Can blow large workpieces

It is customized for professional use in painting industry

High voltage generator is required: ST401A one tow two/one tow four
Model Parameters	ST401A
Operating power supply	110V/60Hz or 220V/50Hz
Consumption current	0.23A or 0.12A
Power	75W
Operating temperature range	0-50℃
Weight	2.25kg
Length of high voltage wire	1.5m
Output voltage	4.6KV X 2 or 4
Output current	4.5mA
Can it be used in explosion- proof environment	No

Technical Parameter

Model	ST202DF
Ion generation mode	Ac type
Material of discharge needle	Tungsten steel
Host material	Stainless steel/ABS fireproof engineering plastics
Air ion supply range	10cm~18cm
Air inlet pipe	Duct with inner diameter Φ 8
Body size	99mm (L)×100mm (W)×900mm (H) Standard cable length 2.5M
Accessories	Instructions/warranty cards/certificates
Performance	Static removal time < 1.5S
Air consumption	0.09m³/min
Noise	56DB
Ozone production	< 0.02ppm or less (measuring distance 200mm)

Product Size
