ST202A AC Ion Nozzle With Large Round Head
Product Features:
1. Quick neutralization of static electricity and good electrostatic dust removal effect;
2. Ion airflow has large coverage area and small volume, which is beneficial to installation;
3. The nozzle has good grounding protection function;
4. Stickon ST401A high-voltage generator is required for integrated use
High voltage generator is required: ST401A one tow two/one tow four
| |
Model Parameters | ST401A |
Operating power supply | 110V/60Hz or 220V/50Hz |
Consumption current | 0.23A or 0.12A |
Power | 75W |
Operating temperature range | 0-50℃ |
Weight | 2.25kg |
Length of high voltage wire | 1.5m |
Output voltage | 4.6KV X 2 or 4 |
Output current | 4.5mA |
Can it be used in explosion- proof environment | No |
Technical Parameter
Model | ST202A |
Ion generation mode | Ac type |
Material of discharge needle | Tungsten steel |
Host material | Stainless steel/ABS fireproof engineering plastics |
Air ion supply range | 8cm~15cm |
Air inlet pipe | Duct with inner diameter Φ 8 |
Body size | 75mm (L)×32mm (W)×72mm (H) Standard cable length is 2.5M m. |
Accessories | Instructions/warranty cards/certificates |
Performance | Static removal time < 1.5S |
Air consumption | 0.01m³/min |
Noise | 56DB |
Ozone production | < 0.02ppm or less (measuring distance 200mm) |
Product Size
Installation Scene
