The wind can be adjusted at will, and the snake can swing the ideal Angle of the wind nozzle at will
Product Features:
1. This product is customized for professional use in coating industry
2. A new type of fixed fan-shaped outlet nozzle
3. The wind power can be adjusted at will, and the snake pipe can swing at an ideal angle at will
4. The action distance of ions can reach 0.7 meters
5. The blowing area is wider than similar products, and the electrostatic and dust removal effect is good
6. It needs to be integrated with Stickon ST402 high voltage generator.
7. Outer sheath (blue bellows) can be added
Model Parameter | ST402A |
Operating power supply | 110V/60Hz or 220V/50Hz |
Consumption current | 0.23A or 0.12A |
Power | 85W |
Operating temperature range | 0-50℃ |
Weight | 2.25kg |
Length of high voltage wire | 1.5m |
Output voltage | 5.6KV×2 or 4 |
Output current | 4.5mA |
Can it be used in explosion- proof environment | No |
Technical Parameter
model | ST201EE |
Ion generation mode | Ac type |
Material of discharge needle | Wolfram steel |
Host material | Iron/ABS fireproof engineering plastics |
Air ion supply range | 10cm~18cm |
Air inlet pipe | Duct with inner diameter φ 8 |
Body size | The length of 99mm(L)×100mm(W)×900mm(H) standard cable is 2.5M |
Appendix | Instructions/warranty cards/certificates |
Performance | Static removal time < 1.5S |
Air consumption | 0.08m³/min |
Noise | 56DB |
Ozone production | < 0.02ppm or less (measuring distance 200mm) |
Product Size
