ST201EF Stainless Steel Bottom Box Rectifier Type Ion Wind Snake Nozzle

Product Features:

1. Manually deform the snake tube, randomly change the direction and point to the target object, and let the ion

airflow blow directly to the target surface

2. It can be directly placed in various working areas and set to automatic control, and the action distance of ions

can reach 1 meter

3. Quick elimination of static electricity makes it easier to clean small and sensitive parts and materials

4. Built-in high-voltage generating needle of fixed electrostatic eliminator capable of providing strong ionic wind

to objects

5. Ingeniously designed as "no electric shock" high voltage discharge

6. Stainless steel bottom box fan-shaped ion wind snake nozzle is a new type of fixed type

7. Stickon ST401A high-voltage generator is required for integrated use

8. Outer sheath (blue bellows) can be added

Model Parameter	ST402A
Operating power supply	110V/60Hz or 220V/50Hz
Consumption current	0.23A or 0.12A
Power	85W
Operating temperature range	0-50℃
Weight	2.25kg
Length of high voltage wire	1.5m
Output voltage	5.6KV×2 or 4
Output current	4.5mA
Can it be used in explosion- proof environment	No

Technical Parameter

Model	ST201EF
Ion generation mode	Rectifier type
Material of discharge needle	Wolfram steel
Host material	Iron/stainless steel/ABS fireproof engineering plastics
Air ion supply range	8cm~15cm
Air inlet pipe	Duct with inner diameter φ 8
Body size	The length of 99mm(L)×100mm(W)×900mm(H) standard cable is 2.5M
Appendix	Instructions/warranty cards/certificates
Performance	Static removal time < 1.5S
Air consumption	0.08m³/min (3kg under 3kg air pressure)
Noise	56DB
Ozone production	< 0.02ppm or less (measuring distance 200mm)

Product Size

Installation Scene
